LX SERIES



LX Series – provides an unaltered view whilst keeping the cool and blocking UV

This film is virtually undetectable on your windows, but it keeps your car cooler and more comfortable whilst protecting your interior. LX70 provides an unaltered view of the outdoors whilst keeping your vehicle naturally cool and saving from harmful UV-rays. Features high optical clarity with low reflectance for uncompromised views, while rejecting 55% of the total solar energy for high heat rejection – keeping you more comfortable and lowering cooling expenses. LX40 Is a slightly darker film with 61% total solar energy rejection and increased glare control.

LX series in short:

  • Visible Light Transmission up to 72%
  • Total Solar Energy Rejection up to 61%
  • IR Reduction: 95%**
  • LX 70: Also for windshields*
  • UV protextion > 99%

Product Name

Visible Light Transmittance

Visible Light
Reflectance (Exterior)

Ultraviolet Light
Blocked

Total Solar
Energy Rejected

LX 70

72%

9%

99%

55%

LX 55

58%

8%

99%

56%

LX 40

39%

6%

99%

60%

LX 25

30%

6%

99%

65%

LX 15

9%

5%

99%

65%

  • Performance results are calculated using NFRC methodology and LBNL Window software, and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and are subject to normal manufacturing variances.
  • Performance results based on film applied to ¼” (6mm) clear glass and a representative automotive glass with a base visible light transmission of 75%. Due to variations in glass performance, these values should not be used to comply with local tinting laws.
